Additive Manufacturing

Provide you particle size distribution and particle shape analysis data of metals.



The manufacturing of metals includes various physical and chemical processes, including smashing, gas, liquid and centrifugal atomization, direct reduction, and extraction. Each method has strict monitoring indexes, such as temperature, pressure, grade, isolation, and protection, to ensure the particle size, particle shape, quality, and other physical and chemical properties of the final products.

Through testing particle size, particle shape and physical properties of powder, Bettersize's instruments can monitor and control product quality, improve product quality and optimize production technology in the development and manufacturing process of metals. The applicable products include aluminium powder, bismuth, bronze, metal carbides, cadmium, chromium, cobalt, copper powder, gallium, hafnium, indium, iron powder, lead, magnesium powder, molybdenum powder, nickel, niobium, platinum, rhenium, rubidium, silicon, silver, strontium, tantalum, tin, titanium dioxide, tungsten, vanadium, yttrium, zinc powder, and zirconium oxide as well as other rare metals and many different alloys of these primary metals.

In addition, particle size and shape analysis is required in powder metallurgy parts manufacturing. Powdered metal components are made from powdered metal using a variety of manufacturing techniques. These techniques include pressing and sintering, powder forging, hot isostatic pressing, electric current assisted sintering, metal injection molding, and selective laser melting.

Size specifications for an atomized metal powder are often tighter than those of many other parts manufacturing processes. The D50 might be smaller and the particle size distribution narrower for complex parts with thin surfaces. Bimodal distributions might be needed to maximize loose-packed density on the laser melter bed to optimise the density and strength and minimize voids in the finished parts.



Particles produced must be highly spherical and smooth-surfaced for good flowability and packing of the laser melter bed.
Contaminants are detrimental in any metal powder, even a single contaminant could cause a point defect in a very thin section of a part. Dynamic image analysis can be used in quality control to monitor if the particles are irregular, rough-surfaced, or translucent. The amount of material that is unfit for purpose can be quantified as a proportion of the sample by volume or number.

Recycling of metal powder can cause it to wear and be contaminated on recycling. If it goes out of spec it has to be melted and re-atomized - a costly expense - to produce in specification powder again.

Quality control of metal powders needs to be effected to meet quality specifications of powder manufacturers' outgoing inspection and the powder metallurgy parts manufacturers' incoming inspection. The morphology and particle size distribution of the metal powder influence flowability, packing density, layer thickness, spreadability, thermal conductivity and so on.

In addition, measuring the morphology and particle size distribution of the powder by the systems below helps in determining the green strength, porosity, sintered strength, and mechanical properties of the formed parts.

Read more

Curated Resources

  • Industry Solution
    Additive Manufacturing Solution Particle and Powder Characterization

    2024-02-28

    Additive Manufacturing Solution - Particle and Powder Characterization

    bigClick
  • Application Note
    Using BeNano 90 Zeta to measure the particle size and zeta potential of multicolor UV-sensitive resins

    2023-07-05

    Using BeNano 90 Zeta to measure the particle size and zeta potential of multicolor UV-sensitive resins

    bigClick
  • Application Note
    Additive manufacturing particle size analysis

    2022-04-06

    Particle characterization for additive manufacturing: Analysis of the key parameters particle size and shape using only one instrument

    bigClick

More resources

Related Particle Size Analyzer

  • Bettersizer S3 Plus

    Bettersizer S3 Plus

    Particle Size and Shape Analyzer

    Measurement range: 0.01 - 3,500μm (Laser System)

    Measurement range: 2 - 3,500μm (Image System)

  • Bettersizer 2600

    Bettersizer 2600

    Laser Diffraction Particle Size Analyzer

    Measurement range: 0.02 - 2,600μm (Wet)

    Measurement range: 0.1 - 2,600μm (Dry)

  • BeVision D2

    BeVision D2

    Dynamic Image Analyzer

    Dispersion type: Dry

    Measurement range: 30 - 10,000μm

    Technology: Dynamic Image Analysis

  • BeVision M1

    BeVision M1

    Automated Static Image Analyzer

    Dispersion type: Dry

    Measurement range: 1 - 10,000μm

    Technology: Automated Static Image Analysis

  • Bevision-S1 Classical and Versatile Static Image Analyzer

    BeVision S1

    Classical and Versatile Static Image Analyzer

    Dispersion type: Dry & Wet

    Measurement range: 1 - 3,000μm

    Technology: Static Image Analysis

  • BeDensi T Pro Series

    BeDensi T Pro Series

    Tapped Density Tester with a Wallet-Friendly Solution

    Number of Workstations: 1-3

    Tapping Speed: 100 - 300 taps/min

    Repeatability: ≤1% variation

  • PowderPro A1

    PowderPro A1

    Automatic Powder Characteristics Tester

    Operation Mode: Automatic

    Tapping Speed: 50 - 300 taps/min

    Repeatability: ≤3% variation

  • BeDensi-B1-S-Scott-Volumeter

    BeDensi B1-S

    Scott Volumeter

    Measurement: Bulk Density

    Compliance with USP, Ph. Eur., ASTM, and ISO standards

  • HFlow 1 Flowmeter Funnel

    HFlow 1

    Flowmeter Funnel

    Measurement: Bulk density and Flow rate

    Compliance with USP, Ph. Eur., ASTM, and ISO standards
